HD DVR LIVE DEMONSTRATION

A link to a live demonstration for the DVR4HD is located below and can be easily accessed on a PC or MAC®.

Speco Technologies has developed multiple viewing options to remotely monitor your DVR. Options such as: Web Browser viewing (IE 6/7/8), Java™ Software for viewing on a MAC®, CMS Software for viewing multiple DVRs, and Mobile Software for viewing DVRs from an Android™, Blackberry™ or iPhone® device.

The DVR shown in this demo is the DVR4HD, which can record 15 FPS at 1080p or 30 FPS at 720p on all 4 channels, with H.264 compression.

All "HD" Series DVRs also include free DDNS service. This allows end-users who's sites have randomly changing IP network addresses (Dynamic IP) to be able to conveniently access the DVR. Simply type in the DVR's URL address. This eliminates costly monthly charges for rights to keep the same (static) IP address.


The format for the Speco Technologies DDNS (the DVR's URL address) for the TH Series DVR is as follows: http://HOSTNAME.DDNS.SPECODDNS.NET

For example, if the Hostname of the DVR is DEMO4TH, the DVR may be accessed via Internet Explorer® by entering: http://DEMOHD.DDNS.SPECODDNS.NET

Speco Technologies' DDNS service will automatically direct to the DVR.


DVR4HD Digital Video Recorder Live Demonstration Link

Product Information








WEB BROWSER VIEWING USING WINDOWS INTERNET EXPLORER® VERSIONS 6, 7, 8

*Please note you may need to permit Internet Explorer® to download Active X controls.

Allow “ACTIVE X” ad-ons to “run”
This may be found in the information bar of I.E.X.

Login ID: user1 (case sensitive)
Password: 4321

Port: 5500

Once connected to the DVR4HD, your screen will display the ‘live view’ web interface.
This ‘live view’ interface allows PTZ control, Playback and Event Log viewing.
It can also initiate snapshots local ‘instant recording’.

Please refer to the: DVR4HD User's Manual (PDF)
for more on Web Browser Interface operation






iPhone® VIEWING INSTRUCTIONS

1. Download Speco Viewer app from Apple iTunes store.

2. Click on the '+' button on the top-right corner of the screen to add a new site.

3. Enter Site name of the DVR.

4. Enter the IP address of the DDNS name of the DVR. If entering DDNS name, enter the full URL.

5. Enter the NETWORK PORT. You can get this information from Setup -> Network -> NETWORK PORT from the DVR menu.
